Lewmar Pro-Series 700G Anchor Windlass 6-7mm Kit

Fast and powerful

The horizontal Lewmar Pro-Series 700G Anchor Windlass is ideal for boats up to 12m (38ft). It's DIY-ready, easy to install and housed in 100% 316 stainless steel, making it well protected. With a push-button control and a built-in manual emergency recovery system, anchoring has never been easier.

Lewmar Pro-Series 700G Anchor Windlass Features:

• Powerful motor providing fast line speed

• Manual emergency recovery equipped all you need is a common 1/2 socket wrench

• Strong 100% 316 stainless steel, including control arm and stripper

• Maximum pulling power: 320kg (700 lb) for the 700 and 454kg (1,000 lb) for the 1000

• Convenient above-deck installation

• For boats up to 12m (38ft)

• 5-year warranty


Lewmar Pro-Series 700G Anchor Windlass Specifications:

• Dimensions: 245 x 178 x 146 mm

• Max Chain: 7mm (1/4in)

• Motor Supply: 12v

• Motor Power: 500w

• Maximum Pull: 320kg (700lb)

• Maximum Line Speed: 32 m/min (105 ft/min)

• Working Load Limit: 79kg (175lb)

• Normal Current Draw: 35 Amp

• Circuit Breaker: 50 Amp

• Weight: 8.5kg

• Chain: 6mm DIN 766 / 7mm DIN 766 / 1/4" ISO G4 / 1/4" BBB

• Rope: 12mm 3-strand and 8-plait


What's in the box:

• Windlass

• Base gasket seal

• Fast mounting studs

• Installation wrench

• Circuit breaker

• Dual-direction solenoid

• Guarded rocker switch


Note: A Pro-Fish conversion kit is available for the Pro-Series Windlass to allow freefall. Wireless remote can only be used if a contactor/solenoid unit is fitted
