Rocna Vulcan Galvanised Anchor 40kg

The item you're looking at is currently unavailable or has limited stock, how about this one instead?

Maxwell Maxset Galvanised Anchor

Details

Details

Rock solid performance

Following on the success of the Rocna, designer Peter Smith was often approached by customers seeking to experience the exceptional holding power and setting performance of a Rocna, but who had difficulties accommodating the roll-bar design on their bow. The Rocna Vulcan Galvanised Anchor is Rocna’s first major design development since the launch of the highly successful and acclaimed Rocna anchor itself. Carefully designed to offer the greatest possible compatibility across a wider range of vessel bow configurations.

Genuine Performance
The original Rocna has ”set the bar” for the highest performance and consistency of behavior when put to the test both by a worldwide array of users and in numerous independent tests. This performance is the result of careful design and engineering by Peter Smith, who has again put to work all of his knowledge and experience to develop a variation on the theme of the ultimate anchor. The new Vulcan capitalises on already finely tuned design elements, infusing many of its elder siblings’s proven performance advantages for an extremely quick and reliable set across a range of seabeds combined with rock-solid holding power.

New solutions for old challenges
Breaking from the Rocna design, the Vulcan features a unique combination of shank and fluke geometry – including an innovative roll-palm at the rear of the fluke – which self-rights the anchor on the seabed without the use of a roll-bar. This is assisted by the V-bulb which extends fluke ballast downward to gain maximum leverage and efficiency. This development permits a larger fluke surface area than competing designs which rely on simple dead weight, while the concave fluke is similar in design to the Rocna, directly equating to more holding power and security.

Rocna Vulcan Galvanised Anchor Features:

• An anchor like no other – the strength and holding power of the Rocna without the roll bar
• Unique shank and fluke geometry combine with an innovative roll-palm to self-right the anchor on the seabed
• The V-bulb extends fluke ballast downward to gain maximum leverage and efficiency
• A larger fluke surface area and higher weight-on-tip than competing designs directly equate to more holding power and security
• The omission of a roll-bar, along with a carefully designed shank profile, ensures compatibility on bow rollers
• These anchors self-deploy from the majority of bow rollers, ensuring ease of use
• High-tensile steel and a unique I+V profile shank design provide resistance to bending

Rocna Vulcan Galvanised Anchor Specifications:

• Finish: Galvanised
• Titan chain type (please refer to the chain specification for your specific windlass model):
  G43 (North America)
  DIN766 (Europe/New Zealand/International)
  Grade L (Australia)

• Recommended chain size: 7/16" (11 mm)
• Recommended Titan shackle: 1/2" (13 mm) High Strength, Forged, Hot Dipped Galvanised Shackle
• Recommended Titan self-righting stainless steel swivel: Type 5 Swivel
• Anchor size: 40 kg (88 lb)
• Fluke area: 1980cm²
• Width: 55.7cm
• Overall length (A): 101.8cm
• B (see images for diagram): 30.6cm
• C (see images for diagram): 31.3cm
• D (see images for diagram): 10cm
• E (see images for diagram): 25.7cm
• S (see images for diagram): 14.5cm
