Newmar Thru-Dex Wiring Box Waterproof
Newmar Thru-Dex Wiring Box Waterproof
Deliver to:
Auckland 0626,
NZ
Estimated:
$5.99
2-hour Click & Collect:
(order before 3pm, in-stock products only)
Our Auckland Shop
Free
Buy now, pay later & Finance Options
Find Local Store
Report incorrect product information
Features:
Specifications:
- Ideal for making wiring connections above or below decks, even in areas subject to occasional spray
- Similar to BX Series junction boxes, but made from rugged, non-corrosive, high impact polypropylene
- Snap-on cover provides watertight seal
- 'Universal' cut-to -fit (see diagram) graduated diameter cable entries accommodate wide cable range
- Multiple position connector strips with 'captive' screw compression wire terminals installed meets ABYC standards (same type as CS-1, page 25)
- Multiple knockouts provided for conduit access (in addition to cable entries)
- IEC Waterproof Rating: IP54 'Water projected in jets against the enclosure from any direction shall have no harmful effects.'
Specifications:
- Model PX-3
- Number of Connector Strips 2
- Positions per Strip 9
- Max Wire Gauge 16
- Number of Cable Entry Ports 7
- Number of Cable Entries Installed 7
- Cable Diameter Range (inches) .14-.99
- Cable Diameter Range (mm) 3.5-25.5
- Box Size (cm) 11.3 x 11.3 x 5.8
