Top quality Fuji tip
Ideal for spinning and casting rods, the Fuji PMGST Silver Frame SiC Rod Tip is a slope frame tip top guide to bind the foot. Thus glued-on type tip top is ideal for spinning and casting rods. So if you need to replace your lost or broken rod's tip top guide or if you're looking for an upgrade, the PMGST Silver Frame Silicone Carbide Rod Tip will take the heat.
SiC
A combination of Silicon (Si) and Carbide (C), SiC has an overwhelming heat conductivity which is 5.7x as high as the hard ring. It would take heat away in a second and keep your valuable line in safe. It's 12x as hard as stainless and diamond-polished for low friction. The SiC ring is 1/3 lighter than stainless. Fuji SiC has almost all desired characteristics that you need in a rod guide.
MG Design
The MG Top is a medium-long tube, medium long-frame model capable of a serious contest with virtually any fish. Mechanically crimped and professionally braised for a lifetime of wear, the MG design features a high entry on the ring-frame braces along with Fuji's original deep pressed ring. Together these features result in unsurpassed ring retention under the worst treatment. Ideal for spinning and casting rods.
Fuji PMGST Silver Frame SiC Rod Tip Features:
- Deep pressed frame
- Sloped frame tip
- Glued-on type
- For spinning and casting rods
- Frame material: Stainless
- Ring material: SiC
- Ring type: LH
Fuji PMGST Silver Frame SiC Rod Tip Specifications:
| Size | L (mm) | H (mm) | OD (mm) |
|---|---|---|---|
| 10H - 2.0 | 24.5 | 13.3 | 2.24 |
| 10H - 2.2 | 24.5 | 13.3 | 2.48 |
| 10H - 2.4 | 24.5 | 13.3 | 2.68 |
| 10H - 2.6 | 27.5 | 13.3 | 2.91 |
| 10H - 3.2 | 30.3 | 13.3 | 3.53 |
| 10H - 3.6 | 30.3 | 13.3 | 3.97 |
| 10H - 4.0 | 30.3 | 13.3 | 4.60 |
| 10H - 4.5 | 30.7 | 13.3 | 5.10 |
| 12 - 3.0 | 29.6 | 14.0 | 3.33 |
| 12 - 3.2 | 29.6 | 14.0 | 3.53 |
| 12 - 3.6 | 30.5 | 14.0 | 3.97 |
| 12 - 4.0 | 30.5 | 1.40 | 4.60 |
| 16 - 3.0 | 33.5 | 19.5 | 3.33 |
| 16 - 3.2 | 33.5 | 19.5 | 3.53 |
| 16 - 3.6 | 33.5 | 19.5 | 3.97 |
| 16 - 4.0 | 33.5 | 19.5 | 4.60 |
How to Measure Rod Guides:
The Height (H) is measured from the base to the top.
The Diameter (D) is the size of the outside of the ceramic liner, not the frame.
On Tip Guides, the Tube Bore (TB) is the internal diameter of the tube.
This should be just a fraction bigger than the outside diameter of the rod blank to allow for some glue.
