Raymarine Axiom 9'' GPS Chartplotter with Navionics Plus NZ/AU

Blazing fast performance and power at your fingertips

A powerful new multifunction navigation system, the new Raymarine Axiom 9" GPS Chartplotter features a rugged all-glass touchscreen display and is powered by the all new LightHouse 3 operating system and blazing fast quad core performance, Axiom will transform your time on the water. Ideal for medium to large sized trailer boats. This unit comes complete with Navionics Plus NZ/AU Chart Card.

Axiom is expandable, so its capabilities can grow, as you need it. It supports the full range of Raymarine accessories, including Quantum radar, FLIR thermal cameras, audio integration, instruments, cameras and Evolution autopilot. Standard Wi-Fi and Bluetooth connectivity allows connection to the latest Raymarine apps for tablets and smartphones.

LightHouse 3 Operating System
LightHouse 3 is fast, fluid and easy to learn. The uncluttered interface is easily personalised for your style of navigating. The home screen offers bold and simple app icons. Customise the home screen with your favourite apps. Want to check your data? Simply swipe the side of the display. It's that easy! LightHouse 3's easy-to-use interface will put you in complete command with just a few touches.

Rugged All-Glass Display
Optimised for flush or surface mounting. Sleek buttonless design with swipe-to-power control.

Uncluttered Radar and Enhanced Thermal Awareness
New radar modes simplify operation along with quick access to sensitivity controls and enhanced status and range displays. Connect to the FLIR M100 or M200 Thermal Camera to actively monitor the scene and provide alerts when any non-water object enter the camera's field of view.

Raymarine Axiom 9" GPS Chartplotter Features:

• 9" Sunlight viewable display
• Lighthouse 3 operating system
• Blazing fast Quad Core processor
• Engineered for quick charting and smooth multi-touch interaction
• Intuitive button-free interface makes it easy to select and view multiple navigation apps
• Can be customised to suit your personal boating and navigation style
• All glass construction looks attractive on any helm
• FLIR Video Analytics with FLIR Thermal Camera connected (sold separately)

Raymarine Axiom 9" GPS Chartplotter Specifications:

General

• Display Size: 9.0" Optically Bonded LCD
• Display Resolution: 800 x 480 WVGA
• Display Type: Multitouch
• Brightness: 1,200 nits
• Viewing Angle: Degrees: 60 / 70 / 70 / 70 (Top / Bottom / Left / Right)
• Dimensions: 244 x 158 x 77 mm
• Weight: 2.04kg
• Mounting: Top, Flush, Front, Bracket
• Waterproof Rating: IPX6 / IPX7
• Operating Temperature: -25 to +55 deg C
• Storage Temp: -30 to +70 deg C
• Voltage: 12V DC (8 V to 16 VDC)

Sensors

• GNSS / GPS: Built-in GNSS Receiver: GPS/GLONASS- 10Hz 72 Channel | External Accessory: RS150 (E70310)
• Radar: Yes - Quantum, Digital, HD Colour and Super HD Colour Radars
• AIS: Yes - NMEA2000
• Autopilot Control: Yes - Evolution Autopilot
• Thermal Night Vision: Yes - IP camera input only
• Video / Camera: Up to 10 IP Cameras
• Audio Integration: NMEA2000 / Bluetooth
• Digital Switching: Yes - Empirbus
• Remote Control: RMK-10 (A80438) and RCU-3 (E62351)

What's in the box:

• MFD (supplied with Trunnion adaptor fitted)
• Trunnion bracket
• Trunnion knobs x 2
• Suncover - Trunnion mount
• Panel mount gasket for surface/flush mounting
• M5x58 Threaded studs x 4
• M5 Thumb nuts x 4
• Documentation pack
• Power/NMEA 2000 cable (with 1.5m power lead and 0.5m NMEA 2000 lead)
• Navionics Plus 50XG NZ/AU Chart Card

Note: Product is a chartplotter unit only and has no fishfinder capability.
