Up (Hydraulic Rams & Linear Drives) ▲

Garmin Class B Drive Unit Linear Drive

#9016074
Warranty Badge - 12-Months
ONLY $6,229.00

Seen a lower price? Ask us to beat it

No payments or interest for 12 months*

💬 Report incorrect product information

Garmin Class B Drive Unit Linear Drive

Click on the image above to view full picture

The item you're looking at is currently unavailable or has limited stock, how about this one instead?
Simrad PUMP-3 Reversible Hydraulic Steering Pump 12V 1.6L/min

Simrad PUMP-3 Reversible Hydraulic Steering Pump 12V 1.6L/min
Why pay $1,799.00
ONLY $1,399.00
SAVE $400.00!
Details

Details

Control your steering system

The Garmin Class B Drive Unit Linear Drive works with the GHP 12 Marine Autopilot System to control your sailboat's steering system. This device is designed for use with larger sailboats with up to 79,000 lbs of displacement.

Garmin Class B Drive Unit Linear Drive Features:
  • Part number: 010-11573-00
  • Designed for use with larger sailboats with up to 79,000 lbs of displacement
  • Compatible with GHP 12 autopilot system
  • Drive Unit Type: Hydraulic linear
  • Stroke Length: 12" (303 mm)
  • Maximum Thrust: 2380 lb (1080 kg)
  • Supply Voltage: 10V to 30V
  • Average Clutch Current at 12V: 1 Amp
  • Average Motor Current at 12V: 3-4 Amps
  • Operating Temperature: -15 °C to 60 °C (5 °F to 140 °F)

Dimensions (WxHxD):

  • Motor: 8.8" x 3" x 3.5" (223 x 76 x 88 mm)
  • Cylinder (centered): 32.7" x 4.1" x 6.3" (830 x 105 x 160mm)
  • Reservoir: 7.9" x 6.1" x 3.3" (200 x 155 x 85 mm)

Garmin Class B Drive Unit Linear Drive Installation Instructions

Note: Garmin items that are currently NOT in stock or have the status "In Stock with Supplier" may take up to 2-3 months to deliver.
