CZone 6-Way Waterproof Keypad Landscape

Full control of circuits

The CZone 6-Way Waterproof Keypad Portrait features dimmable RGB circuit backlighting in a robust IPX7 waterproof enclosure and comes in a portrait orientation. Simplify dashboard installations by removing wiring clutter with a single network cable. Front mount installation with a single 2-1/16" (52mm) hole saw, or rear mount to achieve a flat mount glass dash style look. Keypad comes with a standard label sheet for personalised circuit labelling.

CZone 6-Way Waterproof Keypad Portrait Features:

• IPX7 submersible
• Circuit in operation LED's with blown fuse fault indication
• Dimmable RGB circuit backlighting
• Low profile with 3 mounting options - front, rear and flush mount
• Easy hole saw installation with single plug connection
• Standard label sheet included
• Orientation: Landscape

CZone 6-Way Waterproof Keypad Portrait Specifications:

• Weight: 115g
• Power consumption max: 56mA
• Power consumption standby: 1.8mA
• NMEA2000 connectivity: 1 x CAN Micro-C port
• Warranty: 2 years
• Operating temperature range: -15C to +55C
• Storage temperature range -40C to +85C
• Dimensions: 77 x 107 x 32 mm
• Mounting type: Front and rear mount
• Ingress protection: IPX7
• Compliance: CE, ABYC, NMEA, ISO8846/SAEJ1171 Ignition Protected
• Backlight colour: RGB LED with dimming
• Supply voltage: 9-16V via CAN
• Interface: Tactile Dome / Keypad
