Viper S-Series Gravity Feed Anchor Winch Bundle 90m

The item you're looking at is currently unavailable or has limited stock, how about this one instead?

Viper Chain Sock to Suit Viper Micro 1000 Winch Green

ONLY $49.99

• Details
• Specifications
• Features
• Reviews
• Questions About Product

Details

Details

High performance anchoring

Developed after six years of thorough research and an additional two years of testing, the Viper S-Series Gravity Feed Anchor Winch provides an unprecedented level of free fall perfection. This all-new stainless-steel anchor winch system is pioneered for high performance. Free from any additional electronics, wiring or solenoids, this premium mechanical free fall system provides you peace of mind and reliability in the harshest of boating conditions

Super-fast drop speed
The all-new all-stainless steel Gravity Feed is designed without any additional electronics, wiring or solenoids that can be the downfall in harsh boating environments. The new drop speed will ensure your anchor hits the bottom exactly where you want it, when you want it. At the touch of a switch, the Viper Gravity Feed Free Fall Drum Winch free spools the drum allowing your rope, chain and anchor to fall at a high speed, enabling you to hit your GPS mark each and every time.

Groundbreaking drag mechanism
The implementation of a drag mechanism prevents the drum from over spooling once the anchor hits the ground. If you're anchoring in deep water and/or require high performance anchoring, the new Gravity Feed winch is the one for you – its quiet and efficient operation also conserves your battery due to no power drain on the down drop, and runs at up to 4x faster than some drum winches using the mechanical patented design.

Everything you need
This bundle includes 90 metres of 6mm Double Braid Rope with 8 metres of 6mm Short Link Chain (total of 98 metres rope/chain). With a bullet proof 5-year Viper performance warranty, you can't go past a Viper. Supplied with everything you need to install it, including a 5mm stainless steel sandwich plate, all required stainless steel bolts/screws/nylocs/washers, 2 face plates depending on your dash space and even your rope chain and even swivel are included.

All you have to add is your own cabling or one of the factory made Viper tinned copper marine wiring loom, you will never have to break your back pulling up your anchor and chain again!

Viper S-Series Gravity Feed Anchor Winch Features:

• 1000W submersible S/S electric motor with IP68 Certification
• 28mm solid stainless steel shaft with 3 support bearings
• 8mm marine grade 316 stainless steel plate hand polished to a mirror finish
• Viper 316 stainless steel marine worm drive gear box
• 360-degree motor rotation with 16 different positions
• 5mm S/S sandwich plate and all fixing hardware, installation notes and wiring diagrams included
• 90 bundle includes: 90 metres of 6mm Double Braid Rope with 8 metres of 6mm Short Link Chain (total of 98 metres rope/chain)

Viper S-Series Gravity Feed Anchor Winch Specifications:

• Model: 30072-S
• Max fall rate: 138m per minute
• Max retrieval rate: 45m per minute
• Suit vessel length: 5.7m plus
• Weight: 23kg (winch only)
• Well clearance required: W435 x H266 x D365mm

Note: 3B&S cables are already attached to the motor, sealed and leak tested, ensuring a IP68 rating, just connect your wiring loom to the winch motor cables via the factory fitted marine tinned joiners. Rope and Chain Kit not covered by warranty.
